Silicon Power Industrial eMMC 5.1 Storage Solutions

Branche

Onderwerp

Silicon Power Industrial launched its new eMMC 5.1 Series, featuring two compact storage solutions for industrial and embedded applications.

The series includes the EMC3R0N, available in 32GB, 64GB, and 128GB capacities with TLC NAND and up to 3,000 program/erase (P/E) cycles, and the 16GB EMC5R0N, which uses pSLC technology to deliver up to 30,000 P/E cycles for workloads with frequent data writes.

Both models feature a BGA153 package, sequential read/write speeds of up to 250/200 MB/s, and random read/write performance of up to 3,800/5,500 IOPS.

Compliant with JEDEC eMMC 5.1, the series includes SMART monitoring, LDPC ECC, and power-failure data protection. It supports 3.3V and 1.8V power supplies and operating temperatures from -25°C to 85°C.

Designed for space-constrained systems, the series supports applications such as POS terminals, HMIs, industrial PCs, controllers, IoT gateways, and surveillance systems.

Main features

Includes two models: EMC3R0N and EMC5R0N

EMC3R0N is available in 32GB, 64GB, and 128GB capacities with TLC NAND and up to 3,000 P/E cycles
EMC5R0N offers 16GB capacity with pSLC technology and up to 30,000 P/E cycles
Delivers sequential read/write speeds of up to 250/200 MB/s and random read/write performance of up to 3,800/5,500 IOPS
Features a compact BGA153 package
Supports SDR and DDR transfer modes at clock frequencies up to 200 MHz
Incorporates SMART monitoring, LDPC ECC, and built-in power-failure data protection
Supports 3.3V and 1.8V power supplies
Operates across temperatures from -25°C to 85°C
Complies with the JEDEC eMMC 5.1 standard

New eMMC 5.1 Series for Industrial and Embedded Applications

Main features
