High-Performance MCUs with Advanced Processing and Connectivity

The GD32F505 series MCUs are based on the Arm® v8-M architecture and operate at frequencies of up to 280 MHz. They feature advanced DSP hardware accelerators and a single-precision floating-point unit (FPU), providing efficient processing for compute-intensive applications.

The series integrates three ADCs with sampling rates of up to 3 Msps and support for up to 25 channels. It also includes one fast comparator and one DAC, enabling functions such as fast protection response.

Main features:

• Up to 280 MHz operating frequency with Arm® v8-M architecture
• Advanced DSP hardware accelerators for efficient signal and data processing
• Single-precision FPU for floating-point computation
• Three ADCs with sampling rates of up to 3 Msps
• Up to 25 ADC channels
• Fast comparator and DAC for functions such as fast protection response
• Comprehensive connectivity, including:
• Up to three SPIs
• Two I2Ss
• Two I2Cs
• Three USARTs
• Two UARTs
• Two CAN-FD interfaces
• One USB FS interface
• Multiple package options: LQFP48, LQFP64, LQFP100, QFN48, QFN64, and BGA64
