HOPERF has developed the RFM310C, a Sub-1GHz wireless transceiver module designed specifically for the 868MHz band. Based on the CMT2310A Sub-1GHz wireless transceiver chip, the module is designed to simplify RF hardware development, debugging, and verification while maintaining low power consumption and wireless communication performance. The RFM310C supports multiple modulation schemes, including OOK, (G)FSK, and 4(G)FSK.



Main features

  • 868MHz Sub-1GHz operation — Designed specifically for the 868MHz band
  • Low power consumption — Sleep current as low as 0.6μA
  • +13dBm maximum output power — Supports higher-power wireless transmission
  • -109dBm receiver sensitivity — At 10kbps data rate, 5kHz deviation, and 868MHz
  • Multiple modulation options — Supports OOK, (G)FSK, and 4(G)FSK
  • Wide operating voltage — 1.8V to 3.6V
  • Wide temperature range — -40°C to +85°C
  • Wireless link management — Includes AFC, ACK, and retransmission functions
  • Flexible MCU interface — Standard 4-wire SPI with a 128-byte Tx/Rx FIFO
  • Integrated RF features — Includes RSSI, channel listening, fast frequency hopping, low-voltage detection, and duty-cycle operation
